Coil Winding

Winding solutions for high-precision winding processes

Coil Winding

Nittoku Europe's winding solutions represent state-of-the-art winding technology, automated line concepts, and customized system solutions for the high-precision manufacture of coils, motor windings, and other electrical components. Since 1972, Nittoku has been continuously developing innovative winding machines and complete production lines—from laboratory and stand-alone machines to fully automated series lines.

Benefits

Broad technology portfolio:
From simple laboratory applications to high-speed series production lines
High precision:
Synchronized winding processes and advanced control software
Flexible automation:
Scalable from individual solutions to complete lines
Adaptable to customer requirements:
Special designs depending on component, volume, and quality
Experience since 1972:
Decades of expertise in winding and line concepts

Areas of application

Electric drives & e-mobility

Stator and rotor windings
Hairpin motor windings
Segment core winding

Sensors & Actuators

Chip and miniature coils
Special windings for actuators

Power electronics & electronic components

Air coils
High-precision bobbin and flat wire windings

Industry & Household Appliances

Winding processes for motors, transformers, and coils of all kinds
Integrated automation processes for end-to-end production

Process & System Integration

DJK Europe supports you from the concept and development phase through to series production.

Based on the proven winding technologies of our partner Nittoku, we develop and integrate customized machine and line solutions for your application.

Co-engineering & process development
Early involvement of DJK to optimize product design, winding strategy, and manufacturing process
Feasibility studies & cycle time analyses
Ensuring process stability, quality, and cycle times before series production begins
Complete line integration
Integration of winding processes including insulation, contacting, testing, and automation and handling solutions
After-sales support
Service, training, retrofit, and modernization concepts throughout the entire life cycle of the system

Conclusion

DJK Europe's winding solutions based on Nittoku technology provide you with a technologically advanced, flexible, and efficient platform for high-precision winding processes.

The solutions are ideal for automotive, e-mobility, electronics, and drive applications and can be tailored precisely to your production requirements.
